Introduction

In this series, I will use a small LLM model and fine tune it to answer the request by users by creating the right sql query, I will use Spider1 dataset, this dataset have a ranking and benchmarks for showing the effectiveness of each method, and now have been replaced with Spider 2, but I will use the older version for our example since it smaller dataset and more established

Steps

Here is the current plan for this series, 1. show the data structure and load the data using Grain 2. Prompting + tokenization + zero-shot generation 3. LoRA fine-tuning with Tunix 4. SQL fine tune evaluation with examples 5. Execute generated SQL on SQLite and compare results

Spider dataset

This dataset comes from Spider: A Large-Scale Human-Labeled Dataset for Complex and Cross-Domain Semantic Parsing and Text-to-SQL Task paper from 2018,

Here are some values for you to view for each test/train sample in the Spider dataset. We've shortened the original JSON structure to highlight the most relevant information for human readability.

{
    "db_id": "geo",
    "query": "SELECT city_name FROM city WHERE population  =  ( SELECT MAX ( population ) FROM city WHERE state_name  =  \"wyoming\" ) AND state_name  =  \"wyoming\";",
    "question": "what is the biggest city in wyoming"
}

Explanation of Shortened Parts:

We've focused on the db_id, query, and question fields, as these are the most directly interpretable for understanding the dataset's core purpose: mapping natural language questions to SQL queries for a specific database.

The following fields were omitted for brevity:

• query_toks: This field contains the tokenized version of the SQL query. While useful for machine processing, it's redundant for human understanding when the query field is present.
• query_toks_no_value: Similar to query_toks, but with values replaced by a generic "value" token. This is primarily for model training and not for human review.
• question_toks: The tokenized version of the natural language question. Again, the question field itself is sufficient for human comprehension.
• sql: This is a highly detailed, nested JSON representation of the SQL query's abstract syntax tree (AST). While crucial for semantic parsing tasks, it's overly complex for a quick human overview of the data samples.

Grain

Grain is a data loading library in the JAX ecosystem. I wrote this simple data source to read the Spider JSON files, keep only the fields I need, and attach the database schema definition for each record.

class JsonDataSource:
    def __init__(self, json_paths, keep_fields=("db_id", "query", "question")):
        self.records = load_json_files(json_paths)
        self.keep_fields = keep_fields
        self.db_records = {}

    def __len__(self):
        return len(self.records)

    def __getitem__(self, index):
        raw = self.records[index]

        record = {
            key: raw[key]
            for key in self.keep_fields
            if key in raw
        }

        file_path = f'{os.environ[SPIDER_PATH]}/database/{record["db_id"]}/schema.sql'
        if file_path not in self.db_records:
            record["db_definitions"] = "\n".join(get_create_table_blocks(file_path))
            self.db_records[file_path] = record["db_definitions"]
        else:
            record["db_definitions"] = self.db_records[file_path]

        return record

After defining the data source, I can pass it to Grain and create a loader. For now, I use the development split, disable shuffling, and set batch_size=1 so it is easy to inspect one example at a time.

dev_source = JsonDataSource([
    base_path + "dev.json",
])

dev_loader = grain.load(
    dev_source,
    num_epochs=1,
    shuffle=False,
    batch_size=1,
    worker_count=0,
)

To inspect one sample from the loader, I can use Python’s iter and next:

sample = next(iter(dev_loader))
sample

Here is what one loaded sample looks like with batch_size=1:

{
    "db_id": array(["concert_singer"], dtype="<U14"),
    "query": array(["SELECT count(*) FROM singer"], dtype="<U27"),
    "question": array(["How many singers do we have?"], dtype="<U28"),
    "db_definitions": array([
        '''CREATE TABLE "stadium" (
"Stadium_ID" int,
"Location" text,
"Name" text,
"Capacity" int,
"Highest" int,
"Lowest" int,
"Average" int,
PRIMARY KEY ("Stadium_ID")
);
CREATE TABLE "singer" (
"Singer_ID" int,
"Name" text,
"Country" text,
"Song_Name" text,
"Song_release_year" text,
"Age" int,
"Is_male" bool,
PRIMARY KEY ("Singer_ID")
);
CREATE TABLE "concert" (
"concert_ID" int,
"concert_Name" text,
"Theme" text,
"Stadium_ID" text,
"Year" text,
PRIMARY KEY ("concert_ID"),
FOREIGN KEY ("Stadium_ID") REFERENCES "stadium"("Stadium_ID")
);
CREATE TABLE "singer_in_concert" (
"concert_ID" int,
"Singer_ID" text,
PRIMARY KEY ("concert_ID","Singer_ID"),
FOREIGN KEY ("concert_ID") REFERENCES "concert"("concert_ID"),
FOREIGN KEY ("Singer_ID") REFERENCES "singer"("Singer_ID")
);'''
    ], dtype="<U771"),
}
